Pipe-in Liner™ O

Short Description:

Pipe-in Liner™ O is a durable and efficient solution for the trenchless rehabilitation of oil pipelines. Made from high-quality materials, it ensures a reliable and secure fit inside existing pipes, improving flow efficiency and preventing leaks. The liner is resistant to abrasion, corrosion, and oil damage, offering long-lasting performance. Its easy installation process makes it a cost-effective choice for maintaining and repairing oil pipelines without the need for excavation.

CONTACT NOW

Basic Information

Structure

Data Sheet

Nominal ID of host pipes: 50 mm (2 inches) – 1600 mm (64 inches)

Operating pressure: PN6-PN40

Installation mode: Pull in U-shape Liners

Raw materials: high tenacity fabric reinforcement layer, the outer layer consists of PE with abrasion-resistant properties, the inner layer made of PU or PVDF with better heat-resistant, oil-resistant, or corrosion-resistant properties, etc.

Temperature of media: -40°C to 60°C or -40°C to 120°C

Wall thickness: 4 mm – 9 mm

Pulling speed: 400 m/h

Service life duration: 40 years
