Pipe-in Liner™ G

Short Description:

Pipe-in Liner™ G is an advanced solution for the trenchless rehabilitation of gas pipelines, featuring excellent airtight properties. Made from high-quality materials, it ensures a secure and reliable fit, preventing gas leaks and enhancing pipeline integrity. The liner’s superior airtightness, along with its resistance to corrosion and gas-related damage, guarantees long-lasting performance. Its flexible design allows for easy installation, providing a cost-effective and efficient way to repair gas pipelines without excavation.

CONTACT NOW

Basic Information

Structure

Data Sheet

Nominal ID of host pipes: 50 mm (2 inches) – 1600 mm (64 inches)

Operating pressure: PN6-PN40

Installation mode: Pull in U-shape Liners

Raw materials: high tenacity fabric reinforcement layer, the outer layer consists of PE with abrasion-resistant properties, the inner layer is made of PU with high airtightness

Temperature of media: -40°C to 60°C

Wall thickness: 4 mm – 9 mm

Pulling speed: 400 m/h

Service life duration: 40 years
